698-960 MHz; 1710-2700 MHz; 3400-3800 MHz11dBiUni-directional4G LTE5G2x2 MIMOIP 65-40°C to +80°C
X-Polarised, High Gain, Uni-Directional LTE Antenna (2X2 MIMO)
698 - 960 MHz & 1710 - 3800 MHz, 11dBi
  • New advanced metamaterial technology
  • Exceptional performance over the main 4G/5G bands
  • High Gain for the antenna size
  • Wideband 2x2 MIMO 4G/5G antenna
  • Backwards compatible 2G/3G/4G/LTE/5G antenna
  • Two cross polarised antennas in one enclosure for optimal LTE performance
  • IP65 weather/dust and vandal resistant enclosure.
Close Trigger
Product Overview

The XPOL-2-5G is Poynting’s third generation “V3” of this very popular Cross Polarised (XPOL), cellular band, 2×2 MIMO antenna. The antenna enclosure effectively looks the same as the second generation “V2” but has been completely redesigned on the inside. We have used advanced metamaterial technology, making use of Artificial Magnetic Conductors (AMC) and new registered/patent pending radiator configuration, which is proving to yield exceptional improvements in bandwidth and gain. Radiation patterns of this antenna are exceptionally well controlled, further adding to the performance of the antenna.

The XPOL-2-5G antenna includes the newer 3400 – 3800 MHz bands, which were not previously covered by our V2 and is suitable for 2G, 3G, 4G & 5G. This antenna performs exceptionally well in the following frequency bands: 698 – 960MHz, 1700 – 2170MHz, 2300 – 2700MHz & 3400 – 3800MHz. In addition to the new bands, the gain in the 1700MHz and 2.7GHz is around 3dB higher than the “V2” over the same frequency bands! Our “V2” antenna already outperformed most competitors over these bands, so this substantial improvement in gain shows the benefits of the new advanced materials and novel radiator design.

So, if it was a car, we installed an entirely new technology engine producing twice the power under the bonnet – it may look the same, but just wait until you turn the ignition on!

Product Options
SKU A-XPOL-0002-V3-01 A-XPOL-0002-V3-02 A-XPOL-0002-V3-03
COAX Cable Type Twin HDF-195 N/A Twin HDF-195
COAX Cable Length 5m N/A 10m
Color White White White
Product Accessories
Shipping Details
SKU A-XPOL-0002-V3-01 A-XPOL-0002-V3-02 A-XPOL-0002-V3-03
EAN 6009880915750 6009710920107 6009710920121
HS Code #85291069 #85291069 #85291069
Packaged Weight 1.98kg 1.86kg 2.3kg
Packaged Dimensions 375 x 267 x 98 mm 375 x 267 x 98 mm 375 x 267 x 98 mm
Master Box QTY 10 10 10
Master Box Weight 22.7kg 19kg 24.07kg
Master Box Dimensions 550 x 390 x 500mm 550 x 390 x 500mm 550 x 390 x 500mm
Country of Origin China China China
