OMNI-402
410-470 MHz; 698-2700 MHz; 3400-3800 MHz6.2dBiOmni-Directional4G LTE5G Ready2X2 MIMOIP 67-40°C to +70°C
Omni-Directional, Marine & Coastal LTE MIMO Antenna
410 MHz – 3800 MHz, 6.2dBi
- High performance wideband omni-directional marine antenna
- 2X2 MIMO capability for improved performance
- Easy mounting with feed through 1-inch marine standard adapter bracket included
- Robust and all-weather proof for harsh conditions at sea (IP 68)
- Various 316 stainless steel mounting brackets available optionally
- UV and saltwater protected against tempestuous weather conditions
Closing tab trigger
Your content goes here. Edit or remove this text inline or in the module Content settings. You can also style every aspect of this content in the module Design settings and even apply custom CSS to this text in the module Advanced settings.
Product Overview
The OMNI-402 is an ultra-wide band antenna, which covers all contemporary LTE operating frequencies with excellent balanced gain across all frequencies. The antenna also offers 2X2 MIMO capability from its vertically separated radiating elements, all in the same radome. The antenna design allows the antenna to have superior pattern control over the entire frequency range making the OMNI-402 a true high performance omni-directional MIMO antenna, suitable for marine and coastal applications. Usable in all parts of the world, the OMNI-402 guarantees signal reception almost everywhere. Poynting Antennas achieves this through new antenna configuration using multiple dipoles and a unique (patented) feed network. The antenna is future proof as it covers the 450 MHz LTE frequency band, which is becoming more popular in various regions and countries. This antenna is also 3300 – 3800 MHz capable for coastal and inland use.
Product Options
| SKU | A-OMNI-0402-V1-01 | ||||
|---|---|---|---|---|---|
| Coax Cable Type | Twin HDF-195 | ||||
| Coax Cable Length | 2.00m | ||||
| Connector Type | SMA (m) | ||||
| Colour | White |
Product Accessories
Downloadable Files
Drilling Template g -OMNI-402
Packing Check List -OMNI-402
A-OMNI-0402-V1-01 LTE Marine Antenna Feature Image
A-OMNI-0402-V1-01 LTE Marine Antenna Back View
A-OMNI-0402-V1-01 LTE Marine Antenna Front View
A-OMNI-0402-V1-01 LTE Marine Antenna Side View
View Our Downloads Page for High-Res Images and more
FAQ
Shipping Details
| SKU | A-OMNI-0402-V1-01 | ||||
|---|---|---|---|---|---|
| EAN | 0707273470393 | ||||
| HS Code | #85291069 | ||||
| Packaged Weight | 1.76kg | ||||
| Packaged Dimensions | 704 x 147x 100 | ||||
| Master Box QTY | 10 | ||||
| Master Box Weight | 18.5kg | ||||
| Master Box Dimensions | 350 x 560 x 770 mm | ||||
| Country of Origin | China |
