XPOL-6
1710-2700 MHz11dBiUni-Directional4G LTE2.4 -2.5 GHz2X2 MIMOIP 65-40°C to +70°C
X-Polarised, High Gain, Directional LTE Antenna (2X2 MIMO)
1710 – 2700 MHz, 11dBi
- Cross-polarised with high-gain for LTE applications
- Futureproof wideband LTE antenna and Wi-Fi operational frequencies
- Backwards compatible with 2G and 3G technologies
- Two antennas in one enclosure for optimal LTE performance
- 2X2 MIMO LTE/4G antenna
- Increased connectivity stability
Closing tab trigger
Your content goes here. Edit or remove this text inline or in the module Content settings. You can also style every aspect of this content in the module Design settings and even apply custom CSS to this text in the module Advanced settings.
Product Overview
The XPOL-6 is a unique antenna, which provides a unique solution with a constant high gain for 4G, 3G and 2G networks. The XPOL-6 is a dual-polarised full LTE band antenna and is wall- or pole-mountable. The antenna is equipped to provide client-side MIMO and diversity support for the networks of today and tomorrow. This is done by incorporating two separately fed ultra-wideband elements in a single housing, which is a cost-effective solution for enhancing signal reception. The XPOL-6 antenna increases signal reliability, ensures higher data throughput for users and provides a stable, high quality connection. This improves subscriber’s user experience and secures client retention. It is ideal for any application using the GSM network (LTE/ HSPA/3G/EDGE/GPRS).
Product Options
| SKU | A-XPOL-0006-10M | ||||
|---|---|---|---|---|---|
| Coax Cable Type | Twin HDF-195 | ||||
| Coax Cable Length | 10.00m | ||||
| Connector Type | SMA (m) | ||||
| Colour | Off White |
Downloadable Files
FAQ
Shipping Details
| SKU | A-XPOL-0006-10M | ||||
|---|---|---|---|---|---|
| EAN | 6009693810129 | ||||
| HS Code | #85291069 | ||||
| Packaged Weight | 1.6kg | ||||
| Packaged Dimensions | 360 x 160 x 115 mm | ||||
| Master Box QTY | 13 | ||||
| Master Box Weight | 22.6kg | ||||
| Master Box Dimensions | 520 x 495 x 400 mm | ||||
| Country of Origin | China |
