OMNI-121
698-960 MHz; 1710-2170 MHz; 2300-2700 MHz6dBiOmni-Directional4G LTE2.4-2.5 GHzIP 65-40°C to +70°CFire Resistant
Omni-Directional, Wideband LTE Antenna
698 – 960 MHz, 1.8dBi; 1710 – 2700 MHz, 6dBi
- Cover the GSM 900, GSM 1800/UMTs and LTE Frequency bands
- Increased connectivity stability
- Machine-to-machine (M2M) capabilities
- Consistent high gain over a very wide frequency range
- Popular choice with installers because of its versatile base station
- Vandal and water-resistant enclosure (IP 65)
Closing tab trigger
Your content goes here. Edit or remove this text inline or in the module Content settings. You can also style every aspect of this content in the module Design settings and even apply custom CSS to this text in the module Advanced settings.
Product Overview
This medium gain omni-directional antenna covers the GSM 900, GSM1800 / UMTS and LTE frequency bands. It is a light-weight antenna that is easy to install. This is a cost- effective omni-directional solution as it comes with a 5m cable. The antenna is a popular choice with installers because of its versatile base station capabilities. It is also ideal for machine to machine (M2M) applications that are communicating through GSM network (GPRS/ EDGE/ 3G/ HSPA/ LTE).
Product Options
SKU | A-OMNI-0121-V3 | A-OMNI-0121-01-V3 | A-OMNI-0121-02-V3 | ||
---|---|---|---|---|---|
Coax Cable Type | HDF-195 | HDF-195 | HDF-195 | ||
Coax Cable Length | 8.00m | 5.00m | 4.00m | ||
Connector Type | SMA (m) | SMA (m) | TNC (m) | ||
Colour | Off White | Off White | Off White |
Downloadable Files
Shipping Details
SKU | A-OMNI-0121-V3 | A-OMNI-0121-01-V3 | A-OMNI-0121-02-V3 | ||
---|---|---|---|---|---|
EAN | 6009693810709 | 0707273469977 | 0707273470355 | ||
HS Code | #85291069 | #85291069 | #85291069 | ||
Packaged Weight | 0.72kg | 0.6kg | 0.58kg | ||
Packaged Dimensions | 595 x 130 x 65 | 595 x 130 x 65 | 595 x 130 x 65 | ||
Master Box QTY | 20 | 20 | 20 | ||
Master Box Weight | 14.8kg | 14.4kg | 14.4kg | ||
Master Box Dimensions | 610 x 545 x 352mm | 610 x 545 x 352mm | 610 x 545 x 352mm | ||
Country of Origin | China | China | China |
